China Big Factory Good Price Ac Motor Kit Small Sliding Gate Motors
For Wholesale
Newest Automatic Sliding
Gate Opener Convenient Remote Control For Fence Driveway
For more than ten years, we have adhered to the principle of
quality as the most important thing, and strictly controlled the
products to ensure the longest service life.Our professional
salespersons provide you with one-to-one service, and they will
provide you with professional solutions.
- Power supply range: AC220V/110V±10% 50/60Hz
- Net weight: 12.4kg
- Max loading weight: 600kg
- Working temperature of motor: -25 to +55 Celsius degree
- Working humidity: ≤85%
- Rated power: 370w
- Output gear module: M=4
- Output gear number: Z=16
- Open(close) speed: v=12m/min
- Maximum pull: 22N
- Package one set in one carton
- gate motor sliding gate opener,electric gate opener motor,automatic
gate motor,sliding gate motor,sliding gate operator
swing exterior door motor,articulated swing door opener,dual swing
gate motor,swing gate opener dc,swing arms door operator for swing
gate
swing gate motor heavy duty,heavy duty swing gate motor,automatic
dual swing gate opener with factory pric
Control board Features
One-key cycle control/three-key control optional
Alarm light interface
Adjustable automatic shutdown time
pedestrian mode
apartment model
Limit switch NC/NO optional
Photocell NC/NO optional
Onboard switch power button
Turn motor sensitivity settings on and off separately
The terminals are only used to open, only to close external control
equipment.
Adjustable Resistor Sensitivity
The door automatically stops and reopens when an obstacle is
encountered
Complete set included:
- 1 x Motor with built in Control Panel
- 4 x Remote Controls
- 2 x Manual clutch Keys
- 1 x Motor mounting base plate
- 1 x Instruction Manual
- 2 x Photocell
- 1 x Flash lamp
- 4 x Gear rack
Our sliding door motor has many advantages. Its dust cover can
effectively block rainwater, insects and dust, which can greatly
increase the service life of the motor. |
 |
Using pure copper core, the resistance is small and the performance
is strong. All raw materials are strictly controlled and kept
improving to ensure the efficient operation of the motor. |
 |
|
 |
Selling Points
1) Suitable for residential or commercial sliding doors.
2) Remote control or button full open or pedestrian open.
3) Built-in solar regulator and auto-off function.
4) The door automatically stops and reopens when it encounters an
obstacle.
5) Manually release the clutch in case of emergency or power
failure.
6) Terminals for battery, photocell, flash, solar panel, button,
WIFI APP controller.
7) DIY simple installation. Soft start and slow down gently to
stop.
8) 1 year warranty. WIFI APP function can be added.
