    500Kg Powerful Single Arm Ac Swing Gate Opener For Residential Gates

    Ask Lasest Price
    Brand Name : GATECH
    Model Number : GPK05
    Certification : CE,ROHS
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 2000 sets per month
    • Product Details
    • Company Profile

    500Kg Powerful Single Arm Ac Swing Gate Opener For Residential Gates

    High Quality Wholesale China Factory Supply 500Kg Powerful Single Arm Ac Swing Gate Opener For Residential Gates


    Every homeowner wants to feel safe and secure in their home, and automatic swing doors are one of the best ways to improve the security of your property.

    swing gate opener,swing gate operator

    500Kg Powerful Single Arm Ac Swing Gate Opener For Residential Gates

    Features:

    *Soft start and soft stop.

    *Emergency release key in case of power failure

    *Dual/single gate running mode Adjustable opening/closing interval between master and slave gate

    *Stop/reverse in case of obstruction during gate opening/closing

    *Built in adjustable auto-close

    *Digital display indicates the running situation and setting menu.

    *Reliable electromagnetism limit switch for easy adjustment

    *Buit in max motor running time(MRT) adjustable for multiple safety protection

    *Can be equipment with a wide range of the accessories


    One Leaf 60W 24VDC 500kg 1500RPM Automatic Single Swing Gate Opener For Garden Gate

    500kg Automatic Swing gate openers Technical Specifiation

    Output power of motor12VDC/24VDC 45W
    Rotational speed3200R PM
    Rod's running speed1.6cm/s
    Rod's max travel300mm 400mm 500mm
    Max leaf length5mX2
    Max single-leaf weight500Kg
    Environment Temperature range-20C~+55C
    Protection classIP54
    Continual run time5min

    Advantages:

    Safe and practical: Adopt DC 24V low-voltage motor, use the safety custom key to manually release when the power is off, and automatically stop when encountering obstacles, which is very safe and convenient

    Low noise: The product adopts low-noise metal pinion transmission design, which can effectively reduce noise pollution to the environment and bring you a comfortable experience while being environmentally friendly

    Single leaf or double leaf: one side door can be opened or both sides can be opened at the same time according to the needs, which can increase the needs of different scenarios

    Adjustable time: the opening and closing interval of the double gates can be adjusted, and the maximum running time of the built-in motor can be adjusted to meet your diverse needs


    500Kg Powerful Single Arm Ac Swing Gate Opener For Residential Gates
    500Kg Powerful Single Arm Ac Swing Gate Opener For Residential Gates
    500Kg Powerful Single Arm Ac Swing Gate Opener For Residential Gates

    It is designed to be the strongest kit for heavy duty double swing doors with a maximum length of 3M or a maximum weight of 500KG per door leaf. Scalable and durable die-cast aluminum swingarm for superior performance and longer life.


    Swing gate opener GPK05S package

    The Swing Gate Opener GPK05S is packed in a carton box

    Measurement of carton box : 75*29*29cm

    Shipping weight is 13kgs


    Our Service

    1. We will reply you for your inquiry in 24 hours

    2. Customers design and logo are welcome

    3.Client's demand are welcomed

    4. Credit and quality, the first principle of our management

    5. Offer the design of package if needed

    6. Various options to make payment more convenient

    7. Any suggestions or complaints will be handled at the first time


    FAQ

    Q1: What is the Warranty for swing gate opener ?

    A1:we have 1 year warranty time ,If any quality problems on our side occured in this period ,we will take resposible for it.

    Q2:What is connponents of 1 set swing gate opener ?

    A2:Each Kit swing gate opener inclduing 2motors , 1 control panel , 2 remote controls, 1 user book , 1 set hardward accessories for installation .

    Q3:What is the securiy device for swing gate opener ?

    A3: Our control panel have terminals for infrared sensor ,flashing light , it can avoid some unnecessary accident.

    Q4: How about the OEM?

    A4: We can put costomers' information and logo on the products.

    Q5: What is package size, weight ?

    A5: Package size: 88cm*23cm*20cm . Gross Weight : 23KG

    Q6: What is the Volatage input ?

    A6: Volatage range : 110V-240V

    Q7:Is there any quick release device for power failure?

    A7:Our system have clutches device , when the power failure ,just use a Allen key to release the clutch , and push the door open or close by hand

    Q8:Is there cheap shipping cost to import to our country?

    A8: For small order,express will be best. test 2 sets the ship cost will be competitive .

    For bulk order,sea ship way is best but take much time. For urgent orders,we suggest via air to airport plus our ship partner send to your door.
